4.6 Connecting the SITRANS TF dual chamber housing
4.6.1 Opening the device
Procedure


⑥ Cover of the electrical cable compartment
⑦ Safety catch (back)
Figure 4-1 Rear view of the device
1. Use a 3 mm Allen key to loosen the safety catch (back) ⑦.
2. Unscrew the cover of the electrical cable compartment ⑥.
Connecting
4.6 Connecting the SITRANS TF dual chamber housing
SITRANS TH320/TH420/TR320/TR420/TF320/TF420
Compact Operating Instructions, 03/2018, A5E41865021-AA 39
