en Childproof lock
38
AChildproof lock
Childproof lock The oven has a childproof lock to prevent children from
switching it on by accident.
Note: If the hob is being used, it will not be affected by
the childproof lock on the oven.
Activating the childproof lock
The appliance must be switched off.
Press and hold the c1 button for approx. 4 seconds.
The ' symbol will appear on the display. The
childproof lock has now been activated.
Deactivating the childproof lock
Press and hold the c1 button for approx. 4 seconds.
The ' symbol will go out on the display. The
childproof lock has now been deactivated.
QBasic settings
Ba s i c set t i ngs There are various settings available to you in order to
help use your appliance effectively and simply. You can
change these settings as required.
List of basic settings
Depending on the features of your appliance, not all
basic settings will be available.
--------
Changing the basic settings
The function selector must be set to the "Off" position.
1. Press and hold the v button for approx. 4 seconds.
The first basic setting will appear on the display,
e.g. ™‹‚ ‚.
2. Use the temperature selector to change the setting
as required.
3. Use the @ button to navigate to the next basic
setting.
Basic setting Options
™‹‚
Audible signal duration upon
completion of a cooking time
or timer duration
‚ = approx. 10 seconds
ƒ = approx. 30 seconds*
„ = approx. 2 minutes
™‹ƒ
Amount of time until a setting
is applied
‚ = approx. 3 seconds*
ƒ = approx. 6 seconds
„ = approx. 10 seconds
™‹„
Button tone that sounds when
a button is touched
‹ = off
‚ = on*
™‹…
Brightness of the display illu-
mination
‚ = dark
ƒ = medium*
„ = bright
™‹†
Display time of day
‹ = hide the time
‚ = display the time*
™‹‡
Interior lighting on when
appliance in operation
‹ = no
‚ = yes*
™‹ˆ
Cooling fan run-on time
‚ = short*
ƒ = medium
„ = long
… = extra long
™‹‰
Reset all values to factory set-
tings
‹ = no*
‚ = yes
™‹Š
Activate demo mode
Demo mode is provided for
demonstration purposes only;
the oven does not actually
heat in Demo mode. Demo
mode can only be activated
within 5 minutes of connect-
ing the appliance to the mains
power supply.
‹ = no*
‚ = yes
* Factory setting

Siemens VB578D0S0 Specifications

General

Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Pyrolyze power	10960 W
Number of ovens	1
Total oven power	- W
Microwave cooking	-
Oven thermostat range	50 - 280 °C
Top and bottom heating	Yes
Number of cooking programs	10
Total oven(s) interior capacity	112 L
Maximum temperature (conventional)	280 °C
Current	20 A
Connected load	4200 W
AC input voltage	220 - 240 V
Energy efficiency index (EEI)	81.4
Energy consumption (conventional)	0.83 kWh
Energy consumption (forced convection)	1.4 kWh
Door hinge	down
Cord length	1.15 m
Control type	Rotary, Touch
Display type	LCD
Certification	CE
Door material	Glass
Product color	Black
Control position	Front
Appliance placement	Built-in
Door temperature (max)	40 °C
Effective tray surface area	1830 cm²
Clock type	Electronic
Lamp type	Halogen
Package depth	680 mm
Package width	968 mm
Package height	693 mm

Weight and Dimensions

Depth	570 mm
Width	896 mm
Height	594 mm
Weight	60500 g
Depth with door open	1029 mm
Installation compartment depth	560 mm
Installation compartment width	864 mm
Installation compartment height	604 mm
Interior dimensions (W x D x H)	724 x 417 x 371 mm
Installation compartment width (min)	860 mm
Installation compartment height (min)	600 mm
