Appliance door en
43
5. Remove the two middle panels, along with their
holders.
Note: The two middle panels are not fastened using
retaining pins; instead, they are held in place using
holders.
6. Remove the holders to separate the two middle
panels from one another.
7. Clean the panels with glass cleaner and a soft cloth.
:Warning – Risk of injury!
Scratched glass in the appliance door may develop into
a crack. Do not use a glass scraper, sharp or abrasive
cleaning aids or detergents.
Fitting the door panels
1. Reinsert the two middle panels.
Notes
– You will know that you have inserted the two
middle panels correctly when you can see the
"Low-E" symbol on both panels.
– Make sure that the panels are seated correctly.
All holders must lay flat against the outer panel.
2. Reinsert the inner panel.
Note: The panel must first be inserted into the
retaining bar. The two fastening pins must then
engage in the holders provided for them.
3. Remove the locking pins and close the oven door.
Removing and fitting the appliance door
If the oven is very heavily soiled, the oven door can be
removed for easier cleaning. Normally, however, this is
not necessary.
Removing the appliance door
1. Open the oven door fully.
2. Lock the two hinges on the left and right using the
locking pin (a).
Note: The locking pins must be fully inserted into the
holes in the hinges.
3. Take hold of the sides of the oven door with both
hands and close the oven door by approx. 30° (b).
4. Lift the oven door slightly and pull it out.
Note: Do not close the oven door fully,otherwise the
hinges could become bent and the enamel could be
damaged.
Fitting the appliance door
1. Take hold of the sides of the oven door with both
hands.
2. Slide the hinges into the slots in the oven (a).
Note: The notch at the bottom of the hinges must
engage into the frame of the oven (b).
3. Lower the door.
4. Remove the locking pins.
:Warning – Risk of injury!
If the oven door falls out accidentally or a hinge snaps
shut, do not reach into the hinge. Call the after-sales
service.
:Warning – Risk of injury!
The door may not close properly if the door hinges have
not engaged correctly. This will allow heat to escape
and the parts of the appliance may become very hot. To
prevent this from happening, remove the door again.
Then refit the door as shown in the drawing, making
sure that the groove on the underside of the hinges
engages in the oven frame.
DE
ED

Siemens VB578D0S0 Specifications

General

Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Pyrolyze power	10960 W
Number of ovens	1
Total oven power	- W
Microwave cooking	-
Oven thermostat range	50 - 280 °C
Top and bottom heating	Yes
Number of cooking programs	10
Total oven(s) interior capacity	112 L
Maximum temperature (conventional)	280 °C
Current	20 A
Connected load	4200 W
AC input voltage	220 - 240 V
Energy efficiency index (EEI)	81.4
Energy consumption (conventional)	0.83 kWh
Energy consumption (forced convection)	1.4 kWh
Door hinge	down
Cord length	1.15 m
Control type	Rotary, Touch
Display type	LCD
Certification	CE
Door material	Glass
Product color	Black
Control position	Front
Appliance placement	Built-in
Door temperature (max)	40 °C
Effective tray surface area	1830 cm²
Clock type	Electronic
Lamp type	Halogen
Package depth	680 mm
Package width	968 mm
Package height	693 mm

Weight and Dimensions

Depth	570 mm
Width	896 mm
Height	594 mm
Weight	60500 g
Depth with door open	1029 mm
Installation compartment depth	560 mm
Installation compartment width	864 mm
Installation compartment height	604 mm
Interior dimensions (W x D x H)	724 x 417 x 371 mm
Installation compartment width (min)	860 mm
Installation compartment height (min)	600 mm
