en Rails
42
pRails
Rails Detaching the shelf supports
The shelf supports are each fixed to the side panels of
the cooking compartment at three points.
1. Grip the front of the shelf support and pull it round to
the middle of the cooking compartment.
The front hook of the shelf support will come out of
the hole.
2. Swing the shelf support round further and pull it out
of the rear holes in the side panel.
3. Remove the shelf supports from the cooking
compartment.
Refitting the shelf supports
1. Insert the hooks of the shelf support into the rear
holes in the side panel.
2. Push the front hook of the shelf support into the
hole.
qAppliance door
Ap p l i a n c e door With good care and cleaning, your appliance will retain
its appearance and remain fully functional for a long
time to come. This will tell you how to clean the
appliance door.
Removing and installing the door panels
To facilitate cleaning, you can remove the glass panels
from the oven door.
Removing the door panels
1. Open the oven door fully.
2. Lock the two hinges on the left and right using the
locking pin.
Note: The locking pins must be fully inserted into the
holes in the hinges.
3. Use both hands to lift the bottom of the inner panel
until the fastening pins come out of the holder.
4. Carefully pull the top of the inner panel out of the
retaining strip and lift it to completely free the panel
from the door.
D
E

Siemens VB578D0S0 Specifications

General

Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Pyrolyze power	10960 W
Number of ovens	1
Total oven power	- W
Microwave cooking	-
Oven thermostat range	50 - 280 °C
Top and bottom heating	Yes
Number of cooking programs	10
Total oven(s) interior capacity	112 L
Maximum temperature (conventional)	280 °C
Current	20 A
Connected load	4200 W
AC input voltage	220 - 240 V
Energy efficiency index (EEI)	81.4
Energy consumption (conventional)	0.83 kWh
Energy consumption (forced convection)	1.4 kWh
Door hinge	down
Cord length	1.15 m
Control type	Rotary, Touch
Display type	LCD
Certification	CE
Door material	Glass
Product color	Black
Control position	Front
Appliance placement	Built-in
Door temperature (max)	40 °C
Effective tray surface area	1830 cm²
Clock type	Electronic
Lamp type	Halogen
Package depth	680 mm
Package width	968 mm
Package height	693 mm

Weight and Dimensions

Depth	570 mm
Width	896 mm
Height	594 mm
Weight	60500 g
Depth with door open	1029 mm
Installation compartment depth	560 mm
Installation compartment width	864 mm
Installation compartment height	604 mm
Interior dimensions (W x D x H)	724 x 417 x 371 mm
Installation compartment width (min)	860 mm
Installation compartment height (min)	600 mm
