WL Circuit Breaker selection and application guide
Alarm parameters
The metering function includes the following alarm
set-point functions:
Extended relaying
Protective relays included with the metering function can
monitor the following criteria and initiate a trip if the values
are exceeded.
Protective relay function ANSI device number Setting range Possible delay
Current unbalance 46 5 ... 50% 1 ...15 s
Total harmonic distortion - current 81 THDC 0 ... 50% 5 ...15 s
Voltage unbalance 47 5 ... 50% 1 ...15 s
Undervoltage 27 100 ... 1100V 1 ...15 s
Overvoltage 59 200 ... 1200V 1 ...15 s
Total harmonic distortion - voltage 81 THDV 0 ... 50% 5 ...15 s
Direction of phase rotation 47N
Active power in normal direction 32 1 ... 10000kW 1 ...15 s
Active power in reverse direction 32R 1 ... 10000kW 1 ...15 s
Under frequency 81U 40 ... 70 Hz 1 ...15 s
Over frequency 81O 40 ... 70 Hz 1 ...15 s
Alarm function Setting range Possible delay
Overcurrent 3 ... 10000A 0 ... 255 s
Overcurrent – ground fault 3 ... 10000A 0 ... 255 s
Overcurrent – N-conductor 3 ... 10000A 0 ... 255 s
Phase unbalance – current 5 ... 50% 0 ... 255 s
Demand – current 3 ... 10000A 0 ... 255 s
Total harmonic distortion - current 0 ... 50% 5 ... 255 s
Undervoltage 100...1200V 0 ... 255 s
Overvoltage 200...1200V 0 ... 255 s
Phase unbalance - voltage 5 ... 50% 0 ... 255 s
Total harmonic distortion - voltage 0 ... 50% 5 ... 255 s
Crest factor 0.01 ... 25.5% 0 ... 255 s
Form factor 0.01 ... 25.5% 0 ... 255 s
Active power in normal direction 1 ... 10000kW 0 ... 255 s
Active power in reverse direction 1 ... 10000kW 0 ... 255 s
Leading power factor -0.999 ... 1 0 ... 255 s
Lagging power factor -0.999 ... 1 0 ... 255 s
Demand - active power 1 ... 10000kW 0 ... 255 s
Apparent power 1 ... 10000kVA 0 ... 255 s
Reactive power in normal direction 1 ... 10000kvar 0 ... 255 s
Reactive power in reverse direction 1 ... 10000kvar 0 ... 255 s
Demand - apparent power 1 ... 10000kVA 0 ... 255 s
Demand - reactive power 1 ... 10000kvar 0 ... 255 s
Underfrequency 40 ... 70 Hz 0 ... 255 s
Overfrequency 40 ... 70 Hz 0 ... 255 s
Low Voltage Circuit Breaker
Electronic trip unit (ETU)
