Siemens WL Series Selection And Application Guidelines

WL Circuit Breaker selection and application guide
40
Low Voltage Power Circuit Breaker
UL 1066 Listed catalog number
Interrupting rating, frame size, breaker type and frame rating
Note: Cradle must be ordered separately (see page 49)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Breaker catalog number
Group Interrupt rating (kA) Frame Frame size Fuse (A)
254VAC Max ampere
508VAC 635VAC rating (A) II III
N 50 50 800 X N 2 A 3 0 8
N 50 50 1600 X N 2 A 3 1 6
S 65 65 800 X S 2 A 3 0 8
S 65 65 1600 X S 2 A 3 1 6
S 65 65 2000 X S 2 A 3 2 0
S 65 65 3200 X S 2 A 3 3 2
H 85 65 800 X H 2 A 3 0 8
H 85 65 1600 X H 2 A 3 1 6
H 85 65 2000 X H 2 A 3 2 0
H 85 65 3200 X H 2 A 3 3 2
H 85 85 4000 X H 3 A 3 4 0
H 85 85 5000 X H 3 A 3 5 0
L 100 85 800 X L 2 A 3 0 8
L 100 85 1600 X L 2 A 3 1 6
L 100 85 2000 X L 2 A 3 2 0
L 100 85 3200 X L 2 A 3 3 2
L 100 85 4000 X L 3 A 3 4 0
L 100 85 5000 X L 3 A 3 5 0
M 150 85 3200 X M 3 A 3 3 2
M 150 85 4000 X M 3 A 3 4 0
M 150 85 5000 X M 3 A 3 5 0
F 200 200 800 X 400 F 2 A 3 0 A
F 200 200 800 X 600 F 2 A 3 0 B
F 200 200 800 X 800 F 2 A 3 0 C
F 200 200 800 X 900 F 2 A 3 0 D
F 200 200 800 X 1000 F 2 A 3 0 E
F 200 200 800 X 1200 F 2 A 3 0 F
F 200 200 800 X 1600 F 2 A 3 0 G
F 200 200 800 X 2000 F 2 A 3 0 H
F 200 200 800 X 2500 F 2 A 3 0 J
F 200 200 800 X 3000 F 2 A 3 0 K
F 200 200 1600 X 400 F 2 A 3 1 A
F 200 200 1600 X 600 F 2 A 3 1 B
F 200 200 1600 X 800 F 2 A 3 1 C
F 200 200 1600 X 900 F 2 A 3 1 D
F 200 200 1600 X 1000 F 2 A 3 1 E
F 200 200 1600 X 1200 F 2 A 3 1 F
F 200 200 1600 X 1600 F 2 A 3 1 G
F 200 200 1600 X 2000 F 2 A 3 1 H
F 200 200 1600 X 2500 F 2 A 3 1 J
F 200 200 1600 X 3000 F 2 A 3 1 K
F 200 200 2000 X 400 F 2 A 3 2 A
F 200 200 2000 X 600 F 2 A 3 2 B
F 200 200 2000 X 800 F 2 A 3 2 C
F 200 200 2000 X 900 F 2 A 3 2 D
F 200 200 2000 X 1000 F 2 A 3 2 E
F 200 200 2000 X 1200 F 2 A 3 2 F
F 200 200 2000 X 1600 F 2 A 3 2 G
F 200 200 2000 X 2000 F 2 A 3 2 H
F 200 200 2000 X 2500 F 2 A 3 2 J
F 200 200 2000 X 3000 F 2 A 3 2 K
F 200 200 3200 X 3000 F 3 A 3 3 3
F 200 200 3200 X 4000 F 3 A 3 3 4
F 200 200 3200 X 5000 F 3 A 3 3 5
F 200 200 3200 X 6000 F 3 A 3 3 2
F 200 200 4000 X 4000 F 3 A 3 4 4
F 200 200 4000 X 5000 F 3 A 3 4 5
F 200 200 4000 X 6000 F 3 A 3 4 6
F 200 200 5000 X 5000 F 3 A 3 5 5
F 200 200 5000 X 6000 F 3 A 3 5 0
