Siemens WL Series Selection And Application Guidelines

45
WL Circuit Breaker selection and application guide
Breaking capacity, frame size, switch type and frame rating
Low Voltage Power Circuit Switch
UL 1066 Listed non-automatic catalog number
Switch catalog number
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Group Breaking capacity (kA) Frame Frame size
240VAC Max ampere Fuse
480VAC 600VAC rating (A) II III (A)
L 100 85 800 X L 2 S 3 0 8 S S
L 100 85 1600 X L 2 S 3 1 6 S S
L 100 85 2000 X L 2 S 3 2 0 S S
L 100 85 3200 X L 2 S 3 2 2 S S
L 100 85 4000 X L 3 S 3 4 0 S S
L 100 85 5000 X L 3 S 3 5 0 S S
F 200 200 800 X 1000 F 2 S 3 0 E S S
F 200 200 800 X 1200 F 2 S 3 0 F S S
F 200 200 800 X 1600 F 2 S 3 0 G S S
F 200 200 800 X 2000 F 2 S 3 0 H S S
F 200 200 800 X 2500 F 2 S 3 0 J S S
F 200 200 800 X 3000 F 2 S 3 0 K S S
F 200 200 1600 X 1000 F 2 S 3 1 E S S
F 200 200 1600 X 1200 F 2 S 3 1 F S S
F 200 200 1600 X 1600 F 2 S 3 1 G S S
F 200 200 1600 X 2000 F 2 S 3 1 H S S
F 200 200 1600 X 2500 F 2 S 3 1 J S S
F 200 200 1600 X 3000 F 2 S 3 1 K S S
F 200 200 2000 X 1000 F 2 S 3 2 E S S
F 200 200 2000 X 1200 F 2 S 3 2 F S S
F 200 200 2000 X 1600 F 2 S 3 2 G S S
F 200 200 2000 X 2000 F 2 S 3 2 H S S
F 200 200 2000 X 2500 F 2 S 3 2 J S S
F 200 200 2000 X 3000 F 2 S 3 2 K S S
F 200 200 3200 X 3000 F 3 S 3 3 4 S S
F 200 200 3200 X 4000 F 3 S 3 3 4 S S
F 200 200 3200 X 5000 F 3 S 3 3 5 S S
F 200 200 4000 X 4000 F 3 S 3 4 4 S S
F 200 200 4000 X 5000 F 3 S 3 4 5 S S
F 200 200 4000 X 6000 F 3 S 3 4 6 S S
F 200 200 5000 X 5000 F 3 S 3 5 5 S S
F 200 200 5000 X 6000 F 3 S 3 5 0 S S
