Siemens WL Series - Frame Size 2

Frame size 2 door cut-out
Low Voltage Breaker
Draw-out breaker dimensions
10.39
[263.9]
11.41
[289.9]
5.71
[144.9]
Ø1.42
[Ø36.0]
4.45
[113.0]
1.40
[35.5]
(Max. radii, 4 plc's)
R0.39
[R10.0]
13.38
[339.9]
0.83
[21.1]
2.74
[69.5]
5.19
[131.9]
(Max. radii, 4 plc's)
R0.08
[R2.0]
5.63
[142.9]
1.93
[49.0]
10.98
[278.9]
4.78
[121.5]
R0.08
[R2.0]
(Max. radii, 4 plc's)
10.98
[278.9]
4.78
[121.5]
WL Circuit Breaker selection and application guide
72
