Siemens WL Series Selection And Application Guidelines

33
WL Circuit Breaker selection and application guide
Low Voltage Insulated Case Circuit Switch
UL 489 Listed non-automatic catalog number
Switch locks
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
1
Custom key locks are not available and must be supplied by others. Order Key Lock Provisions if custom keys or keyed alike locks are required.
2
Key lock provided by others.
Switch catalog number
Key lock breaker Key lock breaker Padlock provisions for Padlock provisons
OPEN position (lock OPEN position (lock OPEN and CLOSE for charging
type – KIRK)
1
type – SUPERIOR)
1
push buttons
2
handle
None X
X A
X C
X E
X F
X X G
X X J
X X S
X X U
X X V
X X X W
X X X Z
Miscellaneous options
Key lock breaker
OPEN position (provision only)
2
None N
X B

Siemens WL Series Specifications

General

Brand	Siemens
Model	WL Series
Category	Circuit breakers
Language	English
