Siemens WL Series Selection And Application Guidelines

Low Voltage Power Circuit Switch
UL 1066 Listed non-automatic catalog number
Switch catalog number
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
UL 1066 Listed accessories
External accessories Catalog number
Neutral sensors for metering, 5A secondary
Ratings – 800:5 WLG800NMCT23
Ratings – 1600:5 WLG1600NMCT23
Ratings – 2000:5 WLG2000NMCT23
Ratings – 3200:5 WLG3200NMCT23
Ratings – 4000:5 WLG4000NMCT23
Ratings – 5000:5 WLG5000NMCT23
Replacement mounting bracket for neutral sensor (FSII and FSIII) VLNMCTMB23
Single phase sensor for modified differential GF or source ground return
Modified differential GD (FSII 1200:1) WLGMDGFCT2
Modified differential GD (FSIII 1200:1) WLGMDGFCT3
Modified differential GD (FSII, FSIII 1200:1) WLGNMDGCT23
4-wire residual ground fault sensor
Without copper bus adapters (pass-thru mount) - for 3” max bus bar WLNCT2
Without copper bus adapters (pass-thru mount) - for 3 - 5” max bus bar WLNCT3
With copper bus adapters for bus bar connection - for 3” max bus bar WLNCT2CB
With copper bus adapters for bus bar connection - for 3 - 5” max bus bar WLCNMDGCT23
Internal 3-phase sensor spare part kit
FSII WLCT2
FSIII WLCT3
Miscellaneous external accessories
Crimp lugs for 10#AWG secondary wiring (package of 70) WL10RL
Blank auxiliary plug WLGDAUXPLUG
Auxiliary contact on drawout breaker (knife block) WLCNMD
24V DC trip unit and communications power supply, 2.5A SITOP power, class 2 WLSITOP25
24V DC trip unit and communications power supply, 3.8A SITOP power, class 2 WLSITOP1
Optional metric inserts and bolts for breaker mains (4 each) M8x25 for FSII WLMETRC
Optional metric inserts and bolts for breaker mains (4 each) M10x25 for FSII and FSIII WLMETRC3
Electronic trip unit configuration software kit WLCONFIG
Key lock breaker Key lock breaker Padlock provisions for Padlock provisons
OPEN position (lock OPEN position (lock OPEN and CLOSE for charging
type – KIRK)
1
type – SUPERIOR)
1
pushbuttons
2
handle
None X
X A
X C
X E
X F
X X G
X X J
X X S
X X U
X X V
X X X W
X X X Z
Switch locks
Miscellaneous options
Key lock breaker
OPEN position (provision only)
2
None N
X B
48
WL Circuit Breaker selection and application guide
1
Custom key locks are not available and must be supplied by others. Order Key Lock Provisions if custom keys or keyed alike breakers are required.
2
Key lock provided by others.
