Siemens WL Series Selection And Application Guidelines

32
WL Circuit Breaker selection and application guide
Low Voltage Insulated Case Switch
UL 489 Listed non-automatic catalog number
Switch catalog number
Charging motor, motor switch and operation counter
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Charging motor
operation voltage Motor cut-off Operations
AC DC
switch counter
None X
24 A
48 B
120 125 C
240 250 D
24 X E
48 X F
120 125 X G
240 250 X H
24 X J
48 X K
120 125 X L
240 250 X M
24 X X N
48 X X P
120 125 X X Q
240 250 X X R
Close coil, communications
Close coil
operation voltage
AC DC
Modbus
1
PROFIBUS
1
None X
X G
24 A
24 X N
48 B
48 X S
120 125 C
120 125 X W
240 250 D
240 250 X 2
X H
24 X P
48 X T
120 125 X Y
240 250 X 3
1
Requires 24VDC power supply. Power metering not available and BSS is included.
