WL Circuit Breaker selection and application guide
Low Voltage Insulated Case Switch
UL 489 Listed non-automatic catalog number
Breaking capacity, frame size, switch type and frame rating
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Switch catalog number
1
Group Breaking capacity (kA) Frame Frame size Switch type
240VAC Max ampere Fixed
480VAC 600VAC rating (A) II III mounted drawout
L 100 85 1600 X X L 2 Y 3 1 6 S S
L 100 85 1600 X X L 2 Z 3 1 6 S S
L 100 85 2000 X X L 2 Y 3 2 0 S S
L 100 85 2000 X X L 2 Z 3 2 0 S S
L 100 85 2500 X X L 2 Y 3 2 5 S S
L 100 85 2500 X X L 2 Z 3 2 5 S S
L 100 85 3000 X X L 2 Y 3 3 0 S S
L 100 85 3000 X X L 2 Z 3 3 0 S S
L 100 85 4000 X X L 3 Y 3 4 0 S S
L 100 85 4000 X X L 3 Z 3 4 0 S S
L 100 85 5000 X X L 3 Y 3 5 0 S S
L 100 85 5000 X X L 3 Z 3 5 0 S S
Ready-to-close and auxiliary contacts
Ready-to-close Auxiliary contacts
1 NC contact 2NO+2NC 4NO+4NC
None X
X B
X C
X D
X X H
X X I
