Siemens WL Series Selection And Application Guidelines

WL Circuit Breaker selection and application guide
Low Voltage Insulated Case Breaker Cradles
UL 489 Listed accessories
Cradle accessories Catalog number
3-phase metering CTs, cradle mounted (3 windows per CT)
FSI and FSII Rating – 800:5 WLG8005MCT2
Rating – 1200:5 WLG12005MCT2
Rating – 1600:5 WLG16005MCT2
Rating – 2500:5 WLG25005MCT2
Rating – 3200:5 WLG32005MCT2
FSIII Rating – 3200:5 WLG32005MCT3
Rating – 4000:5 WLG40005MCT3
Rating – 5000:5 WLG50005MCT3
Locking device against opening the cubicle door if breaker is in connect position (FSII and FSIII only) WLDRLC1
37
