Sigma SD15 User Manual

111
WARNING!!
• After cleaning the image sensor, please ensure the dust protector is correctly
attached. If the dust protector is not properly attached, it may move and
damage the image sensor of the camera or the lens.
• Please do not use the blower with the brush for cleaning the image sensor.
If the bruch is attached, it may scratch the image sensor of the camera.
• We recommend using the AC adapter (sold separately) to clean the image
sensor. If the AC adapter is not used, please be sure to fully charge the
battery. If the battery voltage is less than the normal level, the camera will
warn you with an electronic “beep”. In such cases, stop the cleaning process
immediately and fully charge the battery. Failure to do so can result in
damage.
1
Turn the “D”–Dial to the position and
remove the lens.
2
To detach the dust protector, slide it upwards
from its projecting lip with your fingernail. Be
careful not to touch the glass on the dust
protector.
3
Once the dust protector slides upwards, the
lower part of the dust protector is released.
Grasp it and remove the dust protector. (Be
careful not to touch the glass on the dust
protector.)

Sigma SD15 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18 (ISO100)
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	Evaluative Metering, Center-Weighted Average Metering, Center Area Metering, Spot metering
Metering Range	EV 1 to 20 (with 50mm F1.4 at ISO100)
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO (50), 100, 200, 400, 800, 1600, (3200) *( )Extended Mode
Exposure Compensation	±3EV (in 1/3steps)
AE Lock	Push button type
Auto Bracketing	Three or five frames (in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure)
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Storage Media	SD Card / Compatible with SDHC, Multi Media Card
Aspect Ratio	3：2
Resolution	HI：2640 x 1760 MED：1872 x 1248, LOW：1312 x 880
Interfaces	USB 2.0, Video Out (NTSC／PAL)
