72
FLASH EXPOSURE COMPENSATION
It is possible to compensate the flash
output level without changing the
background’s exposure.
While pressing the
button, turn the ”C”-
dial to set the compensation amount.
■ The LCD panel will show 0.0 when you initially press the button.
indicates over exposure
indicates underexposure.
■ Exposure compensation can then be set in 1/3 increments from +3.0 to –3.0
stops.
■ mark will be displayed in the top LCD panel after setting the compensation
amount. Compensation amount will not be displayed. Exposure amount can be
confirmed by pressing the flash exposure amount.
■ It is possible to use the camera for flash exposure compensation of the
external flashgun. If the setting is done by both camera and flashgun, then the
camera’s setting will have priority over the flash’s setting.
WARNING!!
• Once you set the flash Exposure Compensation, the camera will continuously
hold this mode, until the compensation amount is reset to 0.0 value.
Combination of Exposure Compensation and Flash Exposure Compensation
It is possible to make adjustments by using the exposure compensation together
with the flash exposure compensation, such as making the background brighter
and preventing unwanted flash reflections from the subject.
For instance, set the exposure compensation to +2 and the flash exposure
compensation to –2, and the background exposure will be 2 stops over exposed
and the flash exposure be 0 (appropriate).
■ If exposure compensation and flash exposure compensation are set, will
be displayed on the display on the LCD panel, only the exposure
compensation amount will be displayed.

Sigma SD15 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18 (ISO100)
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	Evaluative Metering, Center-Weighted Average Metering, Center Area Metering, Spot metering
Metering Range	EV 1 to 20 (with 50mm F1.4 at ISO100)
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO (50), 100, 200, 400, 800, 1600, (3200) *( )Extended Mode
Exposure Compensation	±3EV (in 1/3steps)
AE Lock	Push button type
Auto Bracketing	Three or five frames (in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure)
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Storage Media	SD Card / Compatible with SDHC, Multi Media Card
Aspect Ratio	3：2
Resolution	HI：2640 x 1760 MED：1872 x 1248, LOW：1312 x 880
Interfaces	USB 2.0, Video Out (NTSC／PAL)
