Sigma SD15 User Manual

114
EXPLANATION OF TERMS
AE
Auto Exposure; by using a built-in exposure meter, camera determines the
correct exposure value, which is combinations of shutter speed and/or aperture
value.
AE Lock
The camera will fix and memorize the exposure value with AE lock. For example,
if a photographic subject is placed in the center and exposure value of the
composition is fixed, the brightness of the background will not influence the
exposure, even if the composition changes and the subject is moved from the
center of a screen. (AE lock button must be used).
AF
Auto Focus; by using a built-in sensor, camera adjusts the focusing automatically.
AF Lock
In AF shooting mode, you can lock the focus on the main subject. For instance,
compose the desired subject in the center of the viewfinder. With the focus fixed
at the same setting, you can re-compose the picture with the subject off-center
and take shots. (Please press the shutter button “Half-way” to use this feature
with Sigma SD15).
Aperture
The lens opening of the iris diaphragm inside the lens. The amount of light, which
strikes the image sensor, is adjusted by the iris diaphragm. The f-number (Focal
Length/Diameter of the Aperture Opening) describes the size of this opening, the
size of the hole can be made larger or smaller. Large aperture (low f-number)
gives bright results and, small aperture (high f-number) gives darker results.
Auto Power-Off
For saving the battery power, the SD15 camera can automatically turn itself off, if
you do not operate it.
CMOS
Complementary Metal Oxide Semiconductor (CMOS) can perform signal
amplication on a per-pixel basis. Significant current flows only during the
switching operation. Therefore a CMOS image sensor can scan data rapidly,
sustain high-speed operation and consume less energy. Recent technological
and production improvements in digital imaging systems are making CMOS more
and more competitive in terms of image quality and cost.
Color Temperature
The numerical expression of the tone of the light, produced by a light source. The
standard unit for color temperature is degrees Kelvin (K). The sunny daylight
used as a standard near 5600 K. Low color temperature implies warmer more
yellow/red light while high color temperature implies a colder more blue light. The
typical color temperature of Tungsten light is 3200 K grade, a personal computer
is 9300 K.

Sigma SD15 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18 (ISO100)
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	Evaluative Metering, Center-Weighted Average Metering, Center Area Metering, Spot metering
Metering Range	EV 1 to 20 (with 50mm F1.4 at ISO100)
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO (50), 100, 200, 400, 800, 1600, (3200) *( )Extended Mode
Exposure Compensation	±3EV (in 1/3steps)
AE Lock	Push button type
Auto Bracketing	Three or five frames (in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure)
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Storage Media	SD Card / Compatible with SDHC, Multi Media Card
Aspect Ratio	3：2
Resolution	HI：2640 x 1760 MED：1872 x 1248, LOW：1312 x 880
Interfaces	USB 2.0, Video Out (NTSC／PAL)
