47
USING THE BUILT-IN FLASH
The cameras have built-in flash for taking pictures at night or in
low light, which is very convenient.
USING THE BUILT-IN FLASH
P
mode, use this mode for automatic
photography. The flash sync speed and
aperture are set automatically. If the subject
is too dark, the flash indicator ”
” in
viewfinder will blink, then you can take a
flash exposure by following.
1
Grasp the built-in flash (see picture) and lift it
up gently.
2
Wait for the
mark to appear in the
viewfinder.
When you lift up the built-in flash, it will start charging. While the built-in flash is
charging, the
mark is not visible, but when the flash is sufficiently charged,
the indicator in viewfinder and on the LCD panel, will show
mark.
During the charging, the shutter cannot be released.
After you finish using the built-in flash, close the flash head by pressing the top
part of the flash down.
When you use the built-in flash continuously, the grip of the camera will
become warm. This is normal and not a defect.
CAUTION !!
The lens hood may intrude into the light path of the built-in flash unit, resulting
in a shadow at the bottom of the picture. (The same phenomenon is possible
with a lens, which has a large front lens and long length) Either remove the
lens hood, or use an external Sigma dedicated flash.
To prevent overheating and protect the built-in flash unit after using continous
shooting with flash, please do not use your flash for a while,.

Table of Contents

Other manuals for Sigma SD15

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sigma SD15 and is the answer not in the manual?

Sigma SD15 Specifications

General IconGeneral
Camera TypeInterchangeable Lens SLR Type Digital Camera
Image Sensor Size13.8 x 20.7mm
Lenses UsedSigma SA Mount Lenses
Picture AngleEquivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens MountSA mount
Imaging Element TypeFOVEON® X3™ (CMOS)
Color Photo Detectors14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording FormatLossless compression RAW Data (12bit), JEPG
White Balance8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder TypePentaprism SLR Viewfinder
Viewfinder Frame Coverage98% horizontal, 98% vertical
Viewfinder Magnification0.9x (50mm F1.4 at infinity)
Eyepoint18mm
Diopter Adjustment Range-3dpt to +1.5dpt
Auto Focus TypeTTL phase difference detection system
AF Operating RangeEV 0 to 18 (ISO100)
Focus ModeSingle AF, Continuous AF (AF Predict function), MF
Metering SystemsEvaluative Metering, Center-Weighted Average Metering, Center Area Metering, Spot metering
Metering RangeEV 1 to 20 (with 50mm F1.4 at ISO100)
Exposure Modes(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO SensivityISO (50), 100, 200, 400, 800, 1600, (3200) *( )Extended Mode
Exposure Compensation±3EV (in 1/3steps)
AE LockPush button type
Auto BracketingThree or five frames (in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure)
Shutter TypeVertical-travel metal focal plane shutter, electronically controlled through entire speed range
Storage MediaSD Card / Compatible with SDHC, Multi Media Card
Aspect Ratio3:2
ResolutionHI:2640 x 1760 MED:1872 x 1248, LOW:1312 x 880
InterfacesUSB 2.0, Video Out (NTSC/PAL)
