Sigma SD15 User Manual

122
Shutter Speeds
1/4000sec to 30sec, Bulb up to 30 (120) sec
*( ) Extended Mode
Flash Synchronization at 1/180sec.
Burst Rate 3.0fps for 21 frames
External Flash
Synchronization
Hot shoe (contact X, with dedicated flash linking
contact)
LCD Monitor Type
Aspect ratio3:2, 3.0" wide viewing angle TFT color LCD
monitor, approx. 460,000 pixels, Coverage area 100%
Reviewing Images
Single-Image display, Zoom-in display,
9 segments thumbnail display, Slide Show
Language
English / Japanese / German / Chinese (Simplified) /
French Spanish / Italian / Korean / Russian
Power Source
lithium ion battery BP-21
AC Adapter SAC-4 (Optional)
Dimensions 144mm/5.7"(W) X 107.3mm/4.2"(H) X 80.5mm/3.2"(D)
Weight 680g / 24oz (without battery)
CONNECTING YOUR CAMERA TO A COMPUTER
The SD15 camera can be connected directly to
a computer using the provided USB cable.
Make sure that the camera is off before
connecting it to the computer. Data transfer
rates will vary depending on the computer and
operating system used. For further information,
please refer to the SIGMA Photo Pro User
Guide, which is available in PDF format on the
supplied CD-ROM.
CONNECTING THE CABLES
z The shutter button and color LCD monitor will
be disabled while the camera is connected to
the computer via a USB cable.
WARNING!!
• Please use only the USB cable supplied with your camera.
USB(2.0)
Te rmi na l

Sigma SD15 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18 (ISO100)
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	Evaluative Metering, Center-Weighted Average Metering, Center Area Metering, Spot metering
Metering Range	EV 1 to 20 (with 50mm F1.4 at ISO100)
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO (50), 100, 200, 400, 800, 1600, (3200) *( )Extended Mode
Exposure Compensation	±3EV (in 1/3steps)
AE Lock	Push button type
Auto Bracketing	Three or five frames (in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure)
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Storage Media	SD Card / Compatible with SDHC, Multi Media Card
Aspect Ratio	3：2
Resolution	HI：2640 x 1760 MED：1872 x 1248, LOW：1312 x 880
Interfaces	USB 2.0, Video Out (NTSC／PAL)
