Sigma SD15 User Manual

40
HOLDING THE CAMERA
To avoid camera shake, which can cause blurring of your photograph, hold
the camera steady.
● Firmly grasp the camera’s grip with your right hand.
● Hold the camera steady with your left hand and support the bottom of the
camera and the lens.
● Place your eye as close to the viewfinder as possible.
● Keep your elbow close to your body and take a half step forward for a more
stable stance.
SHUTTER BUTTON
The shutter button of the SD15 cameras
has two positions. When you press the
shutter button “halfway down”, the
camera’s autofocus and Exposure
Systems activate. When you press the
button “all-the-way down”, and the shutter will release to take a picture.
TIP
• Before you start to take pictures, we recommend that you operate the
camera, to become familiar with the “halfway down” position and other
features of the camera.
z Normally, if the card is not inserted to the camera body, it is not possible to
release the shutter. However, this can be changed from [Release Without
Card] on the Camera Set-up menu (P. 2 8 ).
Disable
(Default)
When the card is not inserted in the camera body, it is not
possible to release the shutter.
Enable
It is possible to release the shutter, even if the card is not
inserted in the camera body.

Sigma SD15 Specifications

General

Camera Type	Interchangeable Lens SLR Type Digital Camera
Image Sensor Size	13.8 x 20.7mm
Lenses Used	Sigma SA Mount Lenses
Picture Angle	Equivalent to 1.7x the focal length of a lens when used on a 35mm SLR camera.
Lens Mount	SA mount
Imaging Element Type	FOVEON® X3™ (CMOS)
Color Photo Detectors	14.06 Million (2652 Columns x 1768 Rows x 3 Layers)
Image Recording Format	Lossless compression RAW Data (12bit), JEPG
White Balance	8 Type (Auto, Sunlight, Shade, Overcast, Incandescent, Fluorescent, Flash, Custom white balance)
Viewfinder Type	Pentaprism SLR Viewfinder
Viewfinder Frame Coverage	98％ horizontal, 98％ vertical
Viewfinder Magnification	0.9x (50mm F1.4 at infinity)
Eyepoint	18mm
Diopter Adjustment Range	-3dpt to +1.5dpt
Auto Focus Type	TTL phase difference detection system
AF Operating Range	EV 0 to 18 (ISO100)
Focus Mode	Single AF, Continuous AF (AF Predict function), MF
Metering Systems	Evaluative Metering, Center-Weighted Average Metering, Center Area Metering, Spot metering
Metering Range	EV 1 to 20 (with 50mm F1.4 at ISO100)
Exposure Modes	(P) Program AE、(A) Aperture Priority AE、 (S) Shutter Speed Priority AE、(M) Manual
ISO Sensivity	ISO (50), 100, 200, 400, 800, 1600, (3200) *( )Extended Mode
Exposure Compensation	±3EV (in 1/3steps)
AE Lock	Push button type
Auto Bracketing	Three or five frames (in 1/3steps, Appropriate Exposure – Under Exposure – Over Exposure)
Shutter Type	Vertical-travel metal focal plane shutter, electronically controlled through entire speed range
Storage Media	SD Card / Compatible with SDHC, Multi Media Card
Aspect Ratio	3：2
Resolution	HI：2640 x 1760 MED：1872 x 1248, LOW：1312 x 880
Interfaces	USB 2.0, Video Out (NTSC／PAL)
