3.3 Error lists
The following summary shows the errors to be detected by the strapping device
3.3.1 Tension process error
No. Process error System response Signalling Rectication
A10 Tension button pressed without releasing
the tension
No tensioning (A1) Short beeping
tone
Insert strap
A13 Rocker lever, tension button or welding
button pressed during the tensioning
process [AUTO]
Cancel tensioning
process
(A1) Short beeping
tone
A14 Permissible number of cycles exceeded
[MAN]
No (more) tensioning (A1) Short beeping
tone
Weld or insert the
strap
A15 Tensioning process timeout Cancel tensioning
process
(A2) 2x short beeping
tone
Tension again
A16 Mechanical components limit switch (S4 =
0) during the tensioning process
Cancel tensioning
process State open
tensioning process
(A1) Short beeping
tone
A18 Limit performance [MAN, SEMI] Cancel tensioning
process
(A2) 2x short beeping
tone
Tension again
A19 Tension button activated with active cam
switch
No tensioning (A1) Short beeping
tone
Insert the strap (actu-
ate rocker)
3.3.2 Process error welding / cooling
No. Process error System response Signalling Rectication
A20 Welding button (S5) activated without
welding release
No welding (A1) Short beeping
tone
Insert and tension
the strap
A24 Tensioning button (S1) activated during
the welding process
No tensioning (A1) Short beeping
tone
A25 Tensioning button (S1) activated during
the cooling process
No tensioning (A1) Short beeping
tone
3.3.3 Processing error “Insert strap”
No. Processing error System response Signalling Rectication
A11 Tensioning button (S1) activated while the
mechanical components are disassem-
bled
No tensioning (A1) Short beeping
tone
A21 Welding button (S5) activated while the
mechanical components are disassem-
bled
No welding (A1) Short beeping
tone
3.3.4 Processing error battery
No. Processing error System response Signalling Rectication
n.a. Battery temperature too low (derating) Tensioning level will be
reduced
Symbols &
ash, force display
ashes
Increases auto-
matically at higher
battery temperature
