Signode BXT3-16 - 3.3.7 System Error Process

16 von 37
V 07.17
Service Manual BXT3-13/16/19ENGLISH
3.3.7 System error process
No. System error System response Signalling Rectication
E50 Cancel welding Open the rocker (S4:0) Cancel welding process. (E2) Error Code, oran-
ge backlight,
symbol pulsating
beep tone, average
Incorrect welding.
– Repeat strapping
– Replace rocker
switch wiring
E51 Cancel cooling: Rocker switch open
(S4:0)
Cancel cooling process. (E2) Error Code, oran-
ge backlight,
symbol pulsating
beep tone, average
Incorrect welding.
– Repeat strapping
– Replace rocker
switch wiring
E53 Timeout lower welding mechanism (S3
!= 1)
– Mechanical components jammed
– Cam switch / wiring defective
Cancel welding process. (E2) Error Code, red
backlight,
symbol pulsating
beep tone, long
Incorrect welding.
– Repeat strapping
– Clean mechanical
components
– Replace cam
switch / wiring
E54 Timeout welding process (End position
not found)
- Mechanical components jammed
Cancel welding process. (E2) Error Code, red
backlight,
symbol pulsating
beep tone, long
Incorrect welding.
– Repeat strapping
– Clean mechanical
components
E55 Performance limitation [AUTO] Cancel tensioning pro-
cess.
(E1) Error Code, oran-
ge backlight,
symbol &
pulsating beep tone,
average
– Repeat auto
tensioning.
E56 Timeout tensioning process [AUTO] Cancel tensioning pro-
cess.
(E1) Error Code, oran-
ge backlight, pulsating
beep tone, average
– Repeat auto
tensioning.
E57 Strap torn or slipped Cancel tensioning
process
idle state, BE = 0
(E1) Error Code, oran-
ge backlight, pulsating
beep tone, average.
Symbol ashes
– Reduce tensioning
force
– Insert the strap
again.
– Clean or replace
the tensioning
wheel
