Silca REKORD - Page 19

Operating manual - English REKORD
Copyright Silca 2 007 17
Key cutting
When the R EKORD key-cutting machine has been turned on by means of switch (O) it i s ready for
cutting:
1) Make sure the gauge rod (G) has been lowered.
2)
Take the carriage up to the tracer point and cutting tool
by releasing the push lever (B).
3) To copy the key, move the carriage sideways from right to left by
means of the lever (D).
4) Turn off the machine with main witch (O) before removing the duplicated key.
5) Remove the keys from the clamps.
6) Turn on the machine with switch (O) and smooth off the ke
y edges by means of the brush (P).
Fig. 14
D
A
B
C
F
H
AB
BRAZIL version
key blank
original key
