SIM5300E_Hardware_Design_V1.02
USB Interface
ADC
USIM Interface
RTC
PWM
Debug Port
SIM5300E is designed with power saving technique where the current consumption is as low as 0.88mA in
sleep mode (BS-PA-MFRMS=9).
SIM5300E integrates TCP/IP protocol and extended TCP/IP AT commands which are very useful for data
transfer applications. For details about TCP/IP applications, please refer to document [2].
2.1 SIM5300E KEY FEATURES
Table 2: SIM5300E key features
Typical power consumption in sleep mode is 0.88mA ( BS-PA-MFRMS=9 )
Support bands: EGSM 900, DCS 1800 and WCDMA B1, WCDMA B8.
SIM5300E can search the 4 frequency bands automatically. The
frequency bands can also be set by AT command “AT+CBAND”. For
details, please refer to document [1].
Compliant to GSM Phase 2/2+
GSM/GPRS:
Class 4 (2W): EGSM900
Class 1 (1W): DCS1800
UMTS:
Class 3 (0.25W): WCDMA
Support CSD transmission
