SIM5300E_Hardware_Design_V1.02
@power level #8<240mA,Typical 147mA
@power level #2<240mA,Typical 121mA
Sleep mode @DRX=8 1.8 mA
Idlemode 11.9mA
@Power MAX Typical 612mA
@Power 21dBm Typical 537mA
@Power 10dBm Typical 187mA
@Power MAX Typical 540mA
@Power 21dBm Typical 446mA
@Power 10dBm Typical 165mA
* In the table above, the current consumption value is the typical value tested in laboratory. In the mass
production stage, there may be differences among each individual.
5.7 ELECTRO-STATIC DISCHARGE
SIM5300E is an ESD sensitive component, so more attention should be paid to the procedure of handling and
packaging. The ESD test results are shown in the following table.
Table 26: The ESD characteristics (Temperature: 25℃ , Humidity: 45 %)
