SIM5300E_Hardware_Design_V1.02
1 INTRODUCTION
This document describes SIM5300E hardware interface in great detail. Also, it is suitable for SIM5300EA.
Both SIM5300E and SIM5300EA have the same function except audio, which is particular for SIM5300EA.
This document can help users to understand SIM5300E interface specifications, electrical and mechanical
details. With the help of this document and other SIM5300E application notes, users can use SIM5300E to
design various applications quickly.
Table 1: The difference of SIM5300E and SIM5300EA
2 SIM5300E OVERVIEW
Designed for global market, SIM5300E is a dual-Band GSM/GPRS/EDGE and dual-band UMTS/HSPA module
that works on frequency bands EGSM 900MHz, DCS 1800MHz and WCDMA2100/900MHz. SIM5300E
features GPRS multi-slot class 12 and supports the GPRS coding schemes CS-1, CS-2, CS-3 and CS-4.
With a tiny configuration of 24*24*2.4mm, SIM5300E can meet almost all space requirements in user
applications, such as M2M, PDA and other mobile devices.
SIM5300E has 68 pins, which provides all hardware interfaces between module and customers’ boards,
which includes:
Power Supply
UART Interface which can support full modem.
Audio channel which includes a microphone input and a receiver output (only for SIM5300EA).
GPIOs
SPI Interface
I2C Interface
