SimCom SIM5300E

SIM5300E_Hardware_Design_V1.02
48
Figure 40: The ramp-soak-spike reflow profile of 5300E
6.2 THE MOISTURE SENSITIVITY LEVEL
The moisture sensitivity level of SIM5300E is 3. The module should be mounted within 168 hours after
unpacking in the environmental conditions of temperature <30°C and relative humidity <60% (RH). It is
necessary to bake the module if the above conditions are not met.
Table 33: Moisture classification level and floor life
Level
Floor Life (out of bag) at factory ambient≤30°C /60% RH or as stated
1
Unlimited at ≤30°C /85% RH
2
1 year
2a
4 weeks
3
168 hours
4
72 hours
5
48 hours
5a
24 hours
