SIM5300E_Hardware_Design_V1.02
49
6
Mandatory bake before use. After bake, it must be reflowed within the time limit specified on the
label.
Notes:
1. If the vacuum package is not open for 6 months or longer than the packing date, baking is also
recommended before re-flow soldering.
2. Product handling, storage and processing must follow IPC / JEDEC J-STD-033.
6.3 BAKING REQUIREMENTS
Because of its sensitivity to moisture absorption, SIM5300E should be baked sufficiently before re-flow
soldering. Otherwise SIM5300E will be at the risk of permanent damage during re-flow soldering. SIM5300E
should be baked 192 hours at temperature 40°C +5°C /-0°C and <5% RH for low-temperature device
containers, or 72 hours at temperature 80°C ±5°C for high-temperature device containers. When baking
SIM5300E modules, note that the plastic tray is not heat resistant. Otherwise the tray may be damaged by
high-temperature during baking.
Table 34: Baking requirements
Baking temperature
Moisture
Time
40°C ±5°C
<5%
192 hours
120°C ±5°C
<5%
4 hours
7 PACKAGING
SIM5300E module support tray packaging.
