SIM5300E_Hardware_Design_V1.02
8
Figure 3： SIM5300EA pin out diagram (Top view)
3.2 PIN DESCRIPTION
Table 4: IO Parameters Definition
Pin Type
Description
PI
Power input
PO
Power output
