Document No: 4020-M010 1st February, 1997 Issue 2.0
3 SPECIFICATION
3.1 GENERAL
System Capacity Minimum 8 Alarm Zone Circuits
Maximum 48 Alarm Zone Circuits
Cabinet Size(mm) Up to 24 Zones : 440H x 500W x 140D
24 - 48 Zones : 400H x 535W x 180D
Cabinet Material 1.5mm Mild grade steel
Cabinet Finish Powder coated
Cabinet Colour Magnolia Ripple
Mounting Wall mount
Shipping Weight 14Kg (without batteries)
Mains Input 240V AC, +6%,-10%,50Hz
Internal Power Supply 24V DC @ 1.5A, or 24V DC @ 4.5A
Standby Battery 24V sealed lead acid 7Ah or 12Ah
Battery Charger 27.6V DC (nominal) @ 0.6A,
PSU Supervision Charger high/low,Battery low/fail
Temperature -5°C to 45°C
Humidity 10% to 90% rh non-condensing.
3.2 INPUTS
Detector Circuits Standard 20V detectors
Maximum detector
quiescent current 2.4mA
Door Switch Bell Isolate, ACF Isolate
Other Supervised door mounted Manual Call Point
3.3 OUTPUTS
Bell Supervised 24V DC @ 1.5A
Brigade(2) Voltage free relay contacts (2A @ 30V dc) N.O. or N.C.
Power Fail(Fault), Master Alarm
Ancillary(2) Voltage free relay contacts (2A @ 30V dc) N.O. or N.C.
3.4 INDICATORS and DISPLAY
Zone Status 2 line by 40 character backlight Liquid Crystal Display with
adjustable contrast control
LED Status Indicators Common Alarm, Fault and Isolate
Bell Isolated, ACF Isolated, Mains Power ON
Audible Buzzer Alarm And Fault Indications
Keypress feedback
