Simplex 4020 Operating Manual

4020 OPERATORS MANUAL Page 5
Document No: 4020-M010 1st February, 1997 Issue 2.0
SPECIFICATION (CONTINUED)
3.5 KEYPAD CONTROLS
Fire Fighters Keypad NEXT, ACKNOWLEDGE, RESET, ISOLATE, BRIGADE
TEST
Service Technician 20 keys including:- Alarm Test, Fault Test,
Keypad Isolate, Battery Test and Lamp test
3.6 PROGRAMMING FUNCTIONS
Input Zone Type Normal, Alarm Verification, AS1668 - 30sec or 60 sec
Latching/non-latching
Zone Labels Maximum 27 characters
Output Control Input list conditions, delay time, Door Isolate
3.7 COMMUNICATIONS PORT (optional)
Type: Serial, 1 x 2120 DC Comms and 1x RS232 Printer port
OR
Serial , 1x Mimic and 1 x RS232 Printer port
3.8 EXPANSION CARDS
8 Input Monitor Card 8 alarm zone circuits
4 Point Control Card 4 x N.O. Voltage free relay contacts (2A @ 30V dc)
supervised or unsupervised.

Simplex 4020 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4020
Display	LCD
Frequency	50/60 Hz
Battery Backup	Yes
NAC Outputs	4
Power	120/240 VAC
Voltage	120/240 VAC
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
Communication Protocol	Optional
