Simplex 4020 Operating Manual

Page 34
Document No: 4020-M010 1st February, 1997 Issue 2.0
8.6 BRIGADE TEST
To test the alarm call circuit to the fire Brigade, press the
BRIGADE TEST key. This will operate the ACF relay
outputs ACF2(Ct2) to ACF4(Ct4) in accordance with the
type of programmed Brigade test.
To view the programmed of Brigade test type use the following procedure:
STEP 1 From the normal display, press the MENU(0) key, the display shows the
following:
0-Edit Point, 1-Program ACF, 2-Time/Date
3-Brigade, 4-Prog Mimic, 5-Next Menu
STEP 2 Press KEY 3 to select option 3-Brigade, the following is displayed:
Current Brigade Type -> 1
Enter Brigade Test Type 0 to 7
STEP 3 Press escape (ESC) key twice to exit and return to the normal display
mode
Table 1.2 lists the available types of Brigade test options.
0
MENU
3
ISO LIST
BRIGADE TEST

Simplex 4020 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4020
Display	LCD
Frequency	50/60 Hz
Battery Backup	Yes
NAC Outputs	4
Power	120/240 VAC
Voltage	120/240 VAC
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
Communication Protocol	Optional
