3
Contents | Broadband 3G™ Radar Installation Guide
Contents
6 Welcome
6 What is Broadband radar?
6 FMCW radar is diff erent:
6 How does FMCW radar work?
7 Additional benefi ts of FMCW radar are:
8 Radar system overview
10 Installation
10 Tools Required
10 Choose the scanner location
11 Considerations for direct roof mounting
14 Connect interconnection cable to the scanner
15 Connect the interconnection cable to radar interface box
17 Connect the Broadband radar to your display
17 Lowrance HDS USA
18 Lowrance HDS Outside USA or with MARPA / Chart overlay
18 Simrad NSS (NMEA2000 network)
19 B&G Zeus
19 Simrad NSO, NSE and NSS, (SimNet network)
20 RI10 Connections
21 Connect power
22 Setup and Con guration
22 Entering radar setup on your display
22 Radar Status
23 Adjust bearing alignment...
23 Adjust local interference reject
23 Adjust antenna height
23 Sidelobe suppression
24 To start the radar
24 RI10 heading source selection
24 Dual radar setup:
26 Dimension Drawings
26 Scanner
27 Radar interface box
27 Maintenance
28 Speci cations
29 Navico Broadband radar part numbers
30 RF exposure compliance certi cate
