Chapter 2-4 CP33 Fundamentals & initial start-up
0-9
The alpha-numeric keys inserts and selects data in data displays.
Keys 1-9 are also Quick-range keys, which each represent a fixed
chart range. Key 0 will center the cursor/ship on the chart.
CLR
Turns cursor off (and centers ship) on chart display. Deletes data in
enter or edit mode.
PWR
Calls up a window where you can adjust the brightness in the screen,
background light in keypad, and select Daylight displays, Night dis-
play or custom made color palettes. Hold 2 seconds to turn the power
off.
2.3 Menu bar
MENU
Toggles the menu bar on/off
To fit the complete menu bar across the screen, some of the menus
have been abbreviated. However, the last selected menu will be high-
lighted, and if it’s an abbreviation of the menu, then the complete
menu title is written above the menu bar.
PILOT
1
CHART
2
POS
3
WP/RTE
4
PILOT
5
ECHO
6
MISC
7
SETUP
1
Highway
2
Waypoint navigation, etc.
Having selected e.g. 4:PILOT from the menu bar, its associated
menus will drop down. Key in the number next to the function you
wish to call forward, or use the cursor key to highlight the function
and press [ENT].
If you want to switch to a different menu, use the cursor key left/
right to move to the adjacent menu.
Most functions in the menus are general, and can be called forward
at any time. Inactive functions in the menu e.g. the waypoint or route
list when empty, will have a different color (normally preset red)
from the rest of the functions.
