CP33 Chart menu and INFO windows Chapter 3-7
3.3 INFO windows
A number of pop-up INFO windows are available mainly from
active chart display. Only a few of the functions in the INFO win-
dows can be accessed from data displays and other displays. Refer to
sections 3.3.x.
3.3.1 Cursor inactive
ENT
With chart in active page, and with cursor off, press [ENT] to call
up an info window with the following to choose from - text in red
are inactive functions:
Scale: 1:6600000 Actual chart scale
No user data
at ship’s position
1
Edit user data
Inactive function
2
Chart info
Refer to Appendix C
3
Find nearest port services
Refer to Appendix C
4
Bearing and dist from A to B
Inactive function
9
Chart setup
Refer to section 3.4
0
Ship to center
PAGE
More user data
MENU
Exit
Exit info window
0
Ship to center will update the chart and place the ship’s position in
the center of the chart display.
PAGE
More user data will toggle between available data on the ship’s
position.
