Simrad Halo User Manual

10 |
Check the parts |Halo pulse compression radar installation manual
Antenna
1
2
3
4
No. Description
1
Radar antenna 3 ft (3.70 ft Antenna 1127 mm (44.37”))
4 ft (4.70 ft Antenna 1431 mm (56.34”))
6 ft (6.69 ft Antenna 2038 mm (80.24”))
2
Dome nuts, M8, 316 s/s
3
Spring washer, M8, 316 s/s
4
Flat washer, M8 x16x1.2, 316 s/s
RI-12 Radar interface module
1 2 3 4
5 6 7 8
No. Description
1
RI-12 Radar interface module
2
Connector for the pedestal interconnection cable
3
Connector for Aux In (NMEA 0183, remote power and park brake)
4
Mounting hard ware
5
Ethernet adapter. RJ45 male to 5 pin female 150 mm (5.9”)
6
Ethernet cable 1.8 m (6 ft)
7
Micro-C T Joiner
8
Micro-C drop cable 1.8 m (6 ft)

Simrad Halo Specifications

General

Networking	Ethernet
IP Rating	IPX6
Range	Up to 72 nm (depending on model)
Operating Frequency	9.4 GHz (X-band)
Frequency	X-Band
Display Compatibility	Simrad multifunction displays
Antenna Length	24" or 20"
Supply Voltage	10-32 V DC
