Simrad Halo User Manual

| 7
Contents | Halo pulse compression radar installation manual
Contents
8 Introduction
9 Check the parts
9 Pedestal
10 Antenna
10 RI-12 Radar interface module
11 Tools required
12 Installation Guidelines
13 Compass safe distance
13 Multi-radar installations
13 Power boat installations
14 Considerations for direct roof mounting
15 Hardware mounting
15 Install the RI-12 radar Interface module
16 Install the pedestal
20 Fitting the antenna to the pedestal
21 Wiring
22 RI-12 connections
23 LED Indicator lights
23 Pedestal Interconnection cable
26 Grounding requirements
27 Remote power control
28 Network
29 NMEA 2000
30 NMEA 0183
30 RI-12 heading source selection:
30 Antenna park
32 Setup and conguration
32 Entering radar setup on your display
32 Select the antenna length
32 Adjust antenna height...
33 Adjust bearing alignment...
34 Sector blanking
34 Adjust open array park angle
34 Sidelobe suppression...
35 Radar Status
35 Reset Radar to factory defaults
36 Control pedestal accent lighting
37 Specications
39 Drawings
39 RI-12
40 Pedestal and antennas
42 Spare Parts
43 Third party mounting options

Simrad Halo Specifications

General

Networking	Ethernet
IP Rating	IPX6
Range	Up to 72 nm (depending on model)
Operating Frequency	9.4 GHz (X-band)
Frequency	X-Band
Display Compatibility	Simrad multifunction displays
Antenna Length	24" or 20"
Supply Voltage	10-32 V DC
