Preface | Halo pulse compression radar installation manual
¼ Note: Most countries accept that RF power density levels below 100 W/m2 cause no signi-
cant RF hazard.
Radio Frequency (RF) Exposure Information
Calculations for radar systems in table below show that the safe distance (for a rotating antenna)
is within the antenna’s turning circle. Irrespective, users should stay well outside the turning
circle of the antenna to avoid injury through impact as it spins
System 100 W /m2 Occupational safe distance 10 W /m2 Public safe distance
All Halo™ Radars 0 cm (0 ft) 28 cm (0.92 ft)
Trademarks
• NMEA 2000 is a registered trademark of the National Marine Electronics Association
• Simrad is a trademark of Kongsberg Maritime AS Company registered in the US and other
countries and is being used under license
• B&G, Lowrance, StructureScan, Navico, SonicHub, SimNet, Skimmer, InsightHD, Halo Pulse
Compression Radar, Broadband Radar and Broadband Sonar are trademarks of Navico,
registered in the US and other countries
About this manual
This manual is a reference guide for installing the Simrad Halo pulse compression radar.
The manual does not cover basic background information about how equipment such as
radars, echosounders and AIS work. Such information is available from our web site:
www.support.simrad-yachting.com
Important text that requires special attention from the reader is emphasized as follows:
¼ Note: Used to draw the reader’s attention to a comment or some important information.
!
Warning: Used when it is necessary to warn personnel that they should proceed
carefully to prevent risk of injury and/or damage to equipment/personnel.
.
