PIN code
Sets a PIN code to prevent unauthorized access to your system's settings.
Note: Record the PIN code and store it in a safe place.
When you establish password protection, the PIN code must be entered when any of the
following are selected. After the correct PIN code is entered, all of them can be accessed
without re-entering the PIN code.
• Settings, activated from the home page or system controls dialog
• Alarms, activated from the toolbar
• Storage, activated from the toolbar
• Store, activated from the toolbar
Power control setup
Determines unit response to signal applied to the power control wire. Refer to "Power control
connection" on page 14.
This setting is only applicable if the yellow wire is used for power control.
• Set to slave if the yellow wire is connected to ignition or to a stand-alone switch
• Set to master to make this device turn other devices connected to the master slave bus on
and off
When a master unit is turned on or off, all units connected to the same master slave bus
turns on or off.
While a master unit is on, a slave unit cannot be turned off.
If no master unit is turned on, slave units can be turned on or off individually.
Advanced
Enabling or disabling features
Use the feature option to enable or disable features that are not automatically enabled or
disabled by the system.
Alarms
Settings
List of all available alarm options in the system, with current settings.
From this list you can activate, deactivate and change alarm limits.
Software setup | NSO evo3S Installation Manual
23
