Simrad NSO evo3S Installation Manual

Contents
7 Introduction
7
Parts included
8 Front controls
8 Connectors
9 Card reader
10 Installation
10 General mounting guidelines
11 Bezel fitment and removal
12 Cable retainer installation
12 Panel mounting
12 Bracket mounting
13 Wiring
13 Wiring guidelines
13 Power
16 NMEA 2000
17 NMEA 0183
18 USB port
19 J1939 port
19 Ethernet
20 HDMI ports
20 Video in
22 Software setup
22 First time startup
22 Software setup sequence
22 The settings dialog
22 System settings
23 Alarms
24 Radar installation
26 Echosounder settings
29 Autopilot settings
30 Fuel settings
32 Wireless settings
32 Network settings
36 3rd party support
36 C-Zone
37 Naviop
37 Mercury
37 Suzuki Marine
37 Yamaha engine integration
37 Evinrude engine integration
37 Power-Pole
38 FLIR camera setup
39 Appendix
39 Dimensional drawings
40 Technical specifications
42 Supported data
6
Contents | NSO evo3S Installation Manual

Simrad NSO evo3S Specifications

General

Display Size	16 inches
Touchscreen	Yes
Power Supply	12/24 V DC
Waterproof Rating	IPX6
Processor	iMX8
RAM	4 GB
Connectivity	Ethernet, NMEA 2000
Operating System	Linux
Mounting	Flush or bracket mount
