16" unit 2 Ports
NMEA 2000 Micro-C (1)
NMEA 0183 1 input/output. 4800, 9600, 19200, 38400
baud - via optional adaptor cable
Video input 2 x Composite video RCA - via optional
adaptor cable
Data card slot 2x microSD
Wireless Internal 802.11b/g/n
Bluetooth Internal
Physical
Dimensions (W x H x D) Refer to "Dimensional drawings" on page 51
Weight (display only)
7" unit 1.1 kg (2.42 lbs.)
9" unit 1.41 kg (3.11 lbs.)
12" unit 3.1 kg (6.83lbs.)
16" unit 4.65 kg (10.25lbs.)
Compass Safe Distance - Metric, imperial 50 cm
Mounting type Bracket (Supplied) or panel mount
Autopilot
Manouveres / Turn patterns U-turn, Spiral-turn, C-turn, Zig-zag, Square-
turn, Lazy S-turn, Depth contour tracking
Steering modes Auto, Nav., No Drift, Follow up, Non-follow
up, Turn patterns, Standby, *Wind, *Wind
Nav. (*Boat type set to Sail)
Sonar
Sonar frequency 40-250kHz 455-800kHz
Sonar output power 1kW RMS
Warranty Period 3 Years
50
Technical specifications | NSS evo3 Installation Manual
