Technical specifications
Technical specifications
Approvals
Compliance FCC, Industry Canada, Radio Equipment
Directive, ACMA, RSM
Display
Resolution
7" unit 1024 x 600
9" unit 1280 x 720
12" unit 1280 x 800
16" unit 1920 x 1080
Type High Visibility SolarMax HD® IPS optically
bonded TFT
Brightness 1200 nits
Touch screen Full touch screen (multi-touch)
Viewing angles in degrees (typical value @
contrast ratio = 10)
80° top/bottom, 80° left/right
Electrical
Supply voltage 12/24 V DC (10 - 31.2 V DC min - max)
Power consumption - Max
7" unit 20 W +- 4 W
9" unit 23 W +- 4 W
12" unit 30 W +- 5 W
16" unit 45 W +- 5 W
Recommended fuse rating
7" unit 3 A
9" unit 3 A
12" unit 5 A
16" unit 5 A
Environmental
Operating temperature range -15°C to +55°C (5°F to 131°F)
Storage temperature -20°C to +60°C (4°F to 140°F)
Waterproof rating IPX 6 and 7
Humidity IEC 60945 Damp heat 66°C (150°F) @ 95%
relative (48 hr)
Shock and vibration 100 000 cycles of 20 G
GPS 10Hz high speed update. WASS, MSAS,
EGNOS, GLONASS
Interface/Connectivity
Ethernet
7" unit 1 Port
9" unit 1 Port
12" unit 2 Ports
8
Technical specifications | NSS evo3 Installation Manual
