1 Display unit
2 Sun cover
3 Bezel trim
4 Power cable
5 Self tapping pozi screws, 4Gx1/2” (x4 for 7", x8 for 9"/12", & x12 for 16" units)
6 Dust caps, different sizes for NMEA 2000 (x1), Ethernet (x1 for 7"/9", x2 for 12"/16")
and Sonar (x2) connectors
7 Dust cap for HDMI connector (12" and 16" only)
8 Dust cap for Video/NMEA 0183 connector
9 Dust cap for USB (16" only)
10 Document pack
11 Foam gasket (self adhesive)
12 U-bracket
13 Bracket knobs
14 Self tapping pozi screws for bracket, 14G x 1”
1
8
Check the contents | NSS evo3 Installation Manual
