OperatingPaneldescription
TheST90OperatingPanelisthemostimportantdeviceforfastandefcientuser
interface.TheOperatingPaneloffersallnecessarycontrolfunctionsfornormaloperationof
theST90.
ThecontrolsprovidedbytheOperatingPanelarearrangedinlogicalfunctionalgroups.This
offersyouclearandeasyoperationwithfastaccesstokeyfunctionality.Themajorityofthe
ST90functionscanbeaccessedusingthetrackballontheOperatingPanelandthemenu
systemshownintheST90presentation.TheOperatingPanelallowsyoutoassigncertain
functionstodedicatedbuttonsandswitches.
Tip
AUSBsocketisprovidedinthetopleftcorneroftheOperatingPanel.Usethissocketto
connectacomputerkeyboard,amouseoraUSBashdrive.
APower:PressthisbuttontoturntheST90onandoff.
•BeforeyouturnontheST90,makesurethatyouhavesufcientwaterdepthto
lowerthetransducer!
•YoumustneverturnontheST90whentheshipisindrydock.Thetransducermay
bedamagedifittransmitsinopenair.
•YoumustneverturnofftheST90bymeansoftheon/offswitchontheProcessor
Unit.YoumustALW AYSusetheOperatingPanel.
BSonarSelect:SincetheOperatingPanelusesEthernettocommunicatewiththe
ProcessorUnit,youcanuseonesinglepaneltocontrolmorethanonesonarsystem.To
changewhichsonartocontrol,pressSonarSelectontheOperatingPanel.Ifyouuse
