337568/A

Startingnormaloperation

Topics

TurningontheST90fornormaluse,page19

Gettingtoknowtheuserinterface,page21

Gettingtoknowpresentationmodesandviews,page23

SelectingNormalmodetostart"pinging",page27

Adjustingtheradiusofthesearcharea,page29

Adjustingtheechosensitivity,page30

Changingtheverticalangleofthesonarbeams,page32

Adjustingthehorizontaldirectionofthesonarbeam,page34

TurningofftheST90,page36

TurningontheST90fornormaluse

InordertousetheST90,youmustrstturniton.ToturnontheST90usethePowerbutton

ontheOperatingPanel.TheST90programstartsautomaticallywhentheProcessorUnitis

turnedon.

Caution

YoumustneverstartST90transmissions(pinging)whentheshipisindrydock.The

transducermaybedamagedifittransmitsinopenair.

Procedure

1Makesurethatyouhavesufcientwaterdepthbelowthekeelbeforeyoulowerthe

transducer.

2Turnonthedisplay(s).

Ifrequired,refertotheinstructionsprovidedbythedisplaymanufacturer.

3OntheOperatingPanel,pressPower,andkeepitdepressedforafewseconds.

Gettingstarted
