Simrad ST90 Quick Start Guide

52
337568/A
Setupmenu
TheSetupmenuprovidesbasicfunctionsrelatedtotheST90installationparametersandits
communicationwithperipheralsystems.
Howtoopen
SelecttheSetupicon.
TheiconislocatedundertheMainmenu.Selecttheicon
onemoretimetoclosethemenu.
Description
Themajorityofthechoicesprovidedbythismenuare
self-explanatory.Onlyspecicfunctionsofparticular
interestareexplainedwithbriefdescriptions.Fordetailed
informationabouteachfunctionanddialogbox,referto
theST90Referencemanualorthecontextsensitiveon-line
help.
•TrackingArea
UseTrackingAreatodenethesizeoftheareathatyouwanttodetectmovingobjectsin.
Aninvisiblearea-thetrackingarea-iscreatedasanacquisitionarea.Inorderforthe
ST90tondandlockontheintendedtarget,itneedstobekeptwithinthistrackingarea.
Iftheintendedtargetfallsoutsidethearea,thetrackingcannotbestarted.
•FishingGear
Bydeningthetypeofshinggearyouareusing,theST90mayprovidemoreaccurate
visualpresentations.UsetheFishingGearSetupdialogboxtochangetheshinggear
propertiestomatchyourownequipment.
•SchoolSelect
Duringnormaloperation,thedetectionandestimationofshschoolsdependsonthe
specieandthedensityoftheschool.SchoolSelectoffersaselectionofspecies.Basedon
yourchoicetheST90willadjustitsoperatingparameterstoachieveoptimalperformance.
SelectSchoolSelectSetuptoadjustthedensityforagivenspecie,ortocreateyouown
schoolparameters.
SimradST90QuickStartGuide
