337568/A

2Turntherelevantrotaryswitchtomaketheadjustment.

Tip

TheOperatingPanelisttedwiththreerotaryswitches.Theswitchesareidentied

withnumbers.Eachswitchcanbeassignedafunctionrelatedtorange,gainor

bearing.InvestigatethefunctionalityprovidedontheOperatingPanelpage.Thispage

islocatedintheInstallationdialogbox.

Optionally:

3InaHorizontalview,selectthebearinglineanddragitsideways.

Optionally:

4ObservetheMainmenu.

ItsdefaultlocationisontherightsideoftheST90presentation.

5SelectBearing.

6Makethenecessaryadjustment.

Select[+]or[-]tochoosetherequestedsetting.

or:

Placethecursoronthebutton.Pressandholdtheleft

mousebutton.Movethecursor

horizontallyoverthebutton.Releasethemousebuttonwhenrequestedvalueisshown.

or:

Selectthemiddleofthebuttontoopenit.Ifyouhaveakeyboardconnectedtothe

ST90,youcantypetherequestedvalue.

7OpenthebuttonandselectApplytoallifyouwishtousethechosensettinginallthe

viewsinthecurrentpresentationmode.

Relatedtopics

Startingnormaloperation,page19
