Shortcutmenus
ShortcutmenusprovideadditionalfunctionalityforST90operation.
Howtoopen
Right-clickintheviewtoopentheshortcutmenu.The
Inspectionviewsdonotprovideshortcutmenus.
Description
Tomakeachoice,right-clickintheviewandselectthe
relevantoptionontheshortcutmenu.
Note
Thefunctionalityprovidedbytheshortcutmenusdiffer
fromoneviewtoanotherdependingontheviewproperties.
TheInspectionviewsdonotprovideshortcutmenus.Functionsfromallshortcutmenus
arelisted.Thescreencaptureisprovidedasanexample.
Inthiscontext,thephrasemarkerisusedtoidentifyavisualsymbolplacedintheST90
presentation.Byplacingamarkerontheechoitisregardedasanobjectthatyoucanact
upon.Ifrelevant,youcanfurtherclassifytheobjectasatarget.
ThephrasetargetisusedtoidentifyanechointheST90presentationthatyouwishtoact
upon.Theechomaybefromamaterialitem,ashallow,reeforrock,orfromsh,sh
schoolsormammals.Youmustdecidewhichechoesthatshallbeclassiedastargets,
andwetheryoushallstarttargettracking.
Ifyouhaveplacedmarkersonseveralechoestomakethemobjects,youcanselectone
oftheseandgiveitprioritystatus.ThebearinglineintherelevantST90viewswill
automaticallybelockedontheobjectwiththisprioritytoreectsitsbearing.Onlyone
singleobjectcanbegivenprioritystatus.Thepriorityisidentiedwitha"P".
InitiateTrack
Duringnormaloperation,someechoesareclearlymoreinterestingthanothers.Inmany
situationsspecicechoesmayberegardedastargets,anditcanbeusefultoreceive
continuousinformationaboutthelocation,speedandheadingofsuchtargets.Tosetup
theST90toprovidesuchinformation,youcanstarttargettracking.
TheInitiateTrackfunctionallowsyoutomanuallystarttargettracking.
Placethecursorovertheechoyouwishtotrack.SelectInitiateTrack.Thetrackedtarget
isregardedasanobject,anditisidentiedwithacircleandtwolines.Thebearing
lineisautomaticallylockedontheobjecttoreectsitsbearing.Anewtrackedobject
isautomaticallygivenprioritystatus.Ifanotherobjecthasthispriority,thestatusis
transferredtothenewobject.Thepriorityisidentiedwitha"P".
