7 General description
7.1 Maxilube pumping centre
The pumping centre of the SKF MaxiLube central lubrication system is designed for pumping lubricant into a
centralised lubrication system. The pumping centre can be controlled and monitored using the control unit in-
tegrated in the changeover valve unit, using external control or by sending SMS messages.
The Maxilube pumping centre consists of a pump (I), a lid set (II), a pressure air regulator (III) and a change
over valve unit (IV) with accessories.
Item Description
I
Pump
II
Lid set (ECO or STA)
III
Pressure air regulator
IV
Changeover valve unit
Figure 1: Construction of SKF Maxilube pumping centre
