10.1.3 Normal mode displays, MonoFlex and and DuoFlex lubrication
systems
Normal mode displays, which show the set values for the lubrication program, can be browsed with the -but-
ton.
Display codes change in the following order when -button is pressed.
Display code Description
The lubrication channel selected on the display. The code is in use only in systems
with two (2) channels. Press the SET button to go to another channel when the code
is displayed.
Lubrication cycle counter.
(Cycle Counter)
Counter reading is added by one unit when lubrication ends. Decimal point is used to
Lubrication cycle setting value as time [h.mm] or pulses depending on the factory set-
ting parameter CYC. Can be set between 0 min – 999 h or 000…999 pulses.
Maximum pressurization time set value [s]. Can be set between 0 s – 999 s.
Set value can be changed to minutes with factory setting parameter Prt.
Can be set between 0 min – 999 min.
(Lubrication, Pressurization time)
Low limit pressure set value [bar/psi]. Can be set between 0-200 bar/0-2900 psi.
(Pressure, Low limit)
Code is in use only in pressure transmitter operation.
High limit pressure set value [bar/psi]. Can be set between 0-200 bar/0-2900 psi.
(Pressure, High limit)
Code is in use only in pressure transmitter operation.
Pressure discharge delay multiplier [n]
(DELay) Delay = P * n [s]
Code is in use only in pressure switch operation.
On: manual operation mode
Pump in use when doubled pumping center (Dualset) is in use:
1: Pump 1 is in use.
2: Pump 2 is in use.
This parameter is visible only when the factory setting parameter dUA has been set
Decimal points are used to separate thousands on lubrication cycle counter reading. Counter max. reading is
49.9 = 49 999.
Depending on the factory setting parameter Pre, the pressure unit on the display is bar or psi. In a psi reading
decimal points are used to separate thousands. For example 1.02 = 1020 psi.
