9.5 Buttons
Note The buttons affect only the channel which is selected on the display.
Button Description

In normal mode, the button is used to browse set values on the display.
In setting mode, the button is used to change the value on the display.

In normal mode in a MonoFlex- and a DuoFlex-system the button is used to browse the
pressure displays of the lines.
In normal mode in a ProFlex system the button is used to go to the pulse counter dis-
play.
In setting mode, the button is used to move to the next character of the display.
When browsing the set values, the button is used to return to normal mode.
SET
In normal mode, the button is used to start extra lubrication, to stop pressurization or re-
set an alarm.
In setting mode, the button is used to save the changed value.
When browsing the set values, the button is used to go to the setting mode.
When a button is pressed, all green LED-signals are lit for a moment. This indicates that the information about
a button being pressed has been transmitted forward.
9.6 Display
Note The display indicates the operation of the channel which is selected on the display.
User interface has a display of 3 characters and 3 decimal points.
The display shows the time and, in pressure transmitter operation, also pressure.
Time and pulse display
The set value for the lubrication cycle and the elapsed interval are displayed as hours and minutes. Decimal
point is used to separate hours and minutes.
Time displayed Display format Example
0 min - 59 min
H.MM
12 min = 0.12
1 h - 9 h 59 min
H.MM
1 h 20 min = 1.20
10 h - 99 h 50 min
HH.M
12 h 50 min = 12.5
100 h - 999 h
HHH.
120 h = 120.
The set value for the maximum pressurization time and elapsed pressurization time are displayed as seconds
without the decimal point.
The set pulse amount and the counted pulses are displayed as integers, without a decimal point.
